Description
| Indoor Model | Unit | MSI-18CRDN8-AG1 | |
| Outdoor Model | MSI-18CRDN8-AG1 | ||
| Type (wall type or others) | Wall type | ||
| Type (On-Off/Inverter) | Inverter | ||
| Type (Cooling only/Heating-Cooling) | Cooling only | ||
| Power Supply | V-Ph-Hz | 220-240V, 1Ph, 50Hz | |
| Gas Type | R32 | ||
| Gas Amount(Kg) | Kg | 0.65 | |
| Cooling | Capacity (Btu/H) | (Btu/H) | 18000 |
| Standard Current (A) | A | 7.2 | |
| Standard Input (W) | W | 1650 | |
| Rated Current (Max Current) | A | 14 | |
| Rated Input (Max Input) | W | 3200 | |
| EER | W/W | 3.42 | |
| EER | (BTU/Hr)/W | 10.91 | |
| SEER | W/W | 4.22 | |
| Star Rating | Star | 3 | |
| Heating | Capacity (Btu/H) | (Btu/H) | N/A |
| Standard Current (A) | A | N/A | |
| Standard Input (W) | W | N/A | |
| Rated Current (Max Current) | A | N/A | |
| Rated Input (Max Input) | W | N/A | |
| EER | W/W | N/A | |
| EER | (BTU/Hr)/W | N/A | |
| SEER | W/W | N/A | |
| Star Rating | Star | N/A | |
| Controller type | Remote/wire | Remote | |
| Indoor Net Weight (KG) | Kg | 11.9 | |
| Indoor Gross Weight (KG) | Kg | 15.2 | |
| Indoor Body Size (mm) | mm | 969x241x320 | |
| Indoor Packing Size (mm) | mm | 1045x315x405 | |
| Outdoor Net Weight (KG) | Kg | 26.6 | |
| Outdoor Gross Weight (KG) | Kg | 29.9 | |
| Outdoor Body Size (mm) | mm | 860X310X555 | |
| Outdoor Packing Size (mm) | mm | 902X356X610 | |
| Compressor | Type | Rotary | |
| Compressor | Brand | GMCC | |
| Suction pressure (Mpa) | Mpa | 4.3 | |
| Discharge Pressure (Mpa) | Mpa | 1.7 | |
| Operation temperature | 0C | 17-30 | |
| Pipe Size (Liquie side, Gas side) | Inch | 1/4, 1/2 | |
| Drain Pipe size | Inch (mm) | Standard | |
| Indoor Air flow(Hi/Mi/Lo) | m3/h | 844/639/547 | |
| IDU Noise level ,dB (Hi/Mi/Lo) | dB | 42.5/36/32.5 | |
| ODU Noise level ,dB | dB | 56.5 | |
| Remarks: The above design and specifications are subject to change without prior notice for product improvement. | |||
Warranty for Residential Usage
Compressor Warranty: 12 Years
Spare Parts Support: 5 Year
Service Warranty: 2 Year
Warranty for Commercial Usage
Compressor Warranty: 3 Years
Spare Parts Support: 1 Year
Service Warranty: 1 Year
Terms & Conditions
This warranty does not cover the following cases –
- The warranty will be invalid if the product is misused, neglected, or rented commercially. The warranty also will be invalid if repaired, replaced modified by unauthorized service personnel.
- The warranty will be invalid if the product serial number/barcode is removed, altered, or duplicated.
- This warranty covers only manufacturing defects in products & workmanship, subject to verification by company personnel
Authority reserves the right to change, extend, correct, stop, or cancel the warranty period without any prior notice.
